Jupiter Condenser – 16MFD @ 500V “Cosmos” Electrolytic Axial range Capacitor
Product Description
The Cosmos Electrolytic Capacitors is a new axial range from Jupiter Condenser!
Inspired from and designs based on early American Wet Electrolytic Capacitors used in audio amplifier, guitar amplifiers and pro audio applications.
See data sheets for specifications on individual values.
Capacitance 16MFD
Tolerance: +/-20%
Rated operation temperature: 85C
Voltage: 500VDC
ESR: 7.74 Ohm Max
DF: 12.84% Max
DC Leakage: 350 uA max. after 5 minutes charge at rated voltage
Ripple T 120Hz: 0.173 Amps @ 65C
Diameter: 0.63″ (16mm)
Length 1.5″ (38mm)
Application: Guitar Amplifier, Audio Amplifier and Pro Audio Application.
Made in USA of US made materials.
Datasheet:
Jupiter Cosmos Electrolytic Capacitors datasheet
